BCD
VERTICAL GLASS ARRISING MACHINE
BLA2
AUTOMATIC VERTICAL EDGING MACHINE
BASB 2500
AUTOMATIC SPACER BAR BENDING MACHINE
BADF 2500
AUTOMATIC DESICCANT FILLING MACHINE
BWPG
AUTOMATIC WASHING AND COMBINING LINE WITH SERVO MOTOR DRIVEN -GAS FILLING PRESS
ASC 3000
AUTOMATIC SPACER BAR CUTTING MACHINE
7000 PRIMA LOGIC
HORIZONTAL BUTYL EXTRUDER
TS 200 E
ROTARY TABLE FOR END OF CONVEYOR TABLE
BLSS
AUTOMATIC TWO COMPONENT EXTRUDER WITH SERVO MOTOR DRIVEN PUMP
BEST COOLER
FREEZER
2200 BEST COLD XL
TWO COMPONENT HYDRAULIC EXTRUSION PUMP WITH TELESCOPIC ARM
| No | Machine Code | Machine Name | Air Consumption | Air Pressure | Power Consumption | Electrical Fuse | Project Details | |
|---|---|---|---|---|---|---|---|---|
| 1 | BCD | Vertical Coating Deletion Machine | 100 lt/min | Min 6 - Maks 8 | 19 kW | 3x80 A | Production Capacity | 900 pcs |
| 2 | BLA2 | Automatic Vertical Edging Machine | 600 lt/min | Min 8 - Maks 9 | 20 kW | 3x80 A | Minimum Employee Number | 6 |
| 3 | BWPG | Automatic Washing and Combing Line With Servo Motor Driven - Gas Filling Press | 880 lt/min | Min 6 - Maks 7 | 50 kW | 3x125 A | Maximum Employee Number | 7 |
| 4 | BLS-S LOGICSEAL | Automatic Two Component Extruder With Servo Motor Driven Pump | 200 lt/min | Min 6 - Maks 7 | 46 kW | 3x80 A | Total Area for Project | 480 m² |
| 5 | 7000 PRIMA LOGIC | Horizontal Butyl Extruder With Servo Motor Driven Pump | 10 lt/min | Min 6 - Maks 8 | 7 kW | 3x32 A | Total Electrical Consumption | 132 kW |
| 6 | 2200 BEST COLD | Two Component Hydraulic Extrusion Pump | 100 lt/min | Min 6 - Maks 8 | 3,8 kW | 3x16 A | Total Air Consumption | 1600 lt/dk |
| 7 | TS 200 - E | Rotary Table For end of Conveyor Table | 30 lt/min | Min 6 - Maks 8 | 0,37 kW | 3x16 A | ||
| 8 | BASB 2500 | Automatic Spacer Bar Bending Machine | 30 lt/min | Min 6 - Maks 8 | 5 kW | 3x32 A | ||
| 9 | BADF 2500 | Automatic Desiccant Filling Machine | 200 lt/min | Min 6 - Maks 8 | 0,75 kW | |||
| 10 | BEST COOLER | Freezer | Min 6 - Maks 8 | 1 kW | 1x16 A | |||
| 11 | BEST RACK | Spacer Bar Rack | 900 lt/min | Min 6 - Maks 8 | 0,75 kW | 1x10 A | ||
