BLA2
VERTICAL GLASS ARRISING MACHINE
BASB 2500
AUTOMATIC SPACER BAR BENDING MACHINE
BADF 2500
AUTOMATIC DESICCANT FILLING MACHINE
BWPG
AUTOMATIC WASHING AND COMBINING LINE WITH SERVO MOTOR DRIVEN -GAS FILLING PRESS
BEST RACK
SPACER BAR RACK
7000 PRIMA LOGIC
HORIZONTAL BUTYL EXTRUDER
TS 200 E
ROTARY TABLE FOR END OF CONVEYOR TABLE
BLSS
AUTOMATIC TWO COMPONENT EXTRUDER WITH SERVO MOTOR DRIVEN PUMP
BEST COOLER
FREEZER
2200 BEST COLD XL
TWO COMPONENT HYDRAULIC EXTRUSION PUMP WITH TELESCOPIC ARM
| No | Machine Code | Machine Name | Air Consumption | Air Pressure | Power Consumption | Electrical Fuse | Project Details | |
|---|---|---|---|---|---|---|---|---|
| 1 | BLA2 | Vertical Glass Arrising Machine | 600 lt/min | Min 8 - Maks 9 | 20 kW | 3x80 A | Production Capacity | 900 pcs |
| 2 | BWPG | Automatic Washing and Combining Line With Servo Motor Driven - Gas Filling Press | 880 lt/min | Min 6 - Maks 7 | 50 kW | 3x125 A | Minimum Employee Number | 6 |
| 3 | BLS-S LOGICSEAL | Automatic Two Component Extruder With Servo Motor Driven Pump | 200 lt/min | Min 6 - Maks 7 | 46 kW | 3x80 A | Maximum Employee Number | 7 |
| 4 | 7000 PRIMA LOGIC | Horizontal Butyl Extruder | 10 lt/min | Min 6 - Maks 8 | 7 kW | 3x32 A | Total Area for Project | 480 m² |
| 5 | 2200 BEST COLD | Two Component Hydraulic Ectrusion Pump | 100 lt/min | Min 6 - Maks 8 | 3,8 kW | 3x16 A | Total Electrical Consumption | 132 kW |
| 6 | TS 200 - E | Rotary Table for end of Conveyor Table | 30 lt/min | Min 6 - Maks 8 | 0,37 kW | 3x16 A | Total Air Consumption | 1600 lt/min |
| 7 | BASB 2500 | Automatic Spacer Bar Bending Machine | 30 lt/min | Min 6 - Maks 8 | 5 kW | 3x32 A | ||
| 8 | BADF 2500 | Automatic Desiccant Filling Machine | 200 lt/min | Min 6 - Maks 8 | 0,75 kW | |||
| 9 | BEST COOLER | Freezer | Min 6 - Maks 8 | 1 kW | 1x16 A | |||
| 10 | BEST RACK | Space Bar Rack | Min 6 - Maks 8 | 0,75 kW | 1x10 A | |||
