ASC 3000
AUTOMATIC SPACER BAR CUTTING MACHINE
BEST FILLER
DESICCANT FILLING MACHINE
BWPG
AUTOMATIC WASHING AND COMBINING LINE WITH SERVO MOTOR DRIVEN -GAS FILLING PRESS
7000 PRIMA LOGIC
HORIZONTAL BUTYL EXTRUDER
TS 200 A
HEIGHT AND SPEED ADJUSTABLE ROTARY TABLE
BEST COOLER
FREEZER
2200 BEST COLD
TWO COMPONENT HYDRAULIC EXTRUSION PUMP
| No | Machine Code | Machine Name | Air Consumption | Air Pressure | Power Consumption | Electrical Fuse | Project Details | |
|---|---|---|---|---|---|---|---|---|
| 1 | BWPG | Automatic Washing and Combining Line With Servo Motor Driven - Gas Filling Press | 880 lt/min | Min 6 - Maks 8 | 50 kW | 3x125 A | Production Capacity | 900 pcs |
| 2 | 7000 PRIMA LOGIC | Horizontal Butyl Extruder | 10 lt/min | Min 6 - Maks 8 | 7 kW | 3x32 A | Minimum Employee Number | 6 |
| 3 | 2200 BEST COLD | Two Component Hydraulic Extrusion Pump | 100 lt/min | Min 6 - Maks 8 | 3,8 kW | 3x16 A | Maximum Employee Number | 7 |
| 4 | ASC 3000 | Automatic Spacer Bar Cutting Machine | 5 lt/min | Min 6 - Maks 8 | 1,7 kW | 3x16 A | Total Area for Project | 215 m² |
| 5 | BEST FILLER | Desiccant Filling Machine | 50 lt/min | Min 6 - Maks 8 | 1 kW | 1x6 A | Total Power Consumption | 65 kW |
| 6 | TS 200 - A | Height and Speed Adjustable Rotary Table | 30 lt/min | Min 6 - Maks 8 | 0,37 kW | 1x10 A | Total Air Consumption | 1300 lt/min |
| 7 | BEST COOLER | Freezer | Min 6 - Maks 8 | 1 kW | 1x16 A | |||
| 8 | BEST RACK | Spacer Bar Rack | Min 6 - Maks 8 | 0,75 kW | 1x10 A | |||
